Application Field
Gold Assay Lab
Jewelry Showroom / Factory
Precious Metal Metallurgical Plant
Quality Inspection Authorities
Gold Jewelry Hallmark Center
Pawnshop
Precious metal recovery

Humanized Design
Safer: X-ray integrated safety device — shutter interacts with interlock; housing is linked with high voltage enable terminal to prevent radiation.

Performance features
The most advanced detection technology – Amptek’s SDD(Silicon Drift Detector), with ultra-high
resolution as low as 135eV.
large detecting area (25mm²); receiving more information in unit t Advantage: ime; better count rate and resolution; higher precious metal detection efficiency; better SNR and lower detection limit.
Digital multichannel technology
Advantage: effectively improve output efficiency, realize ultra-high counting rate, guarantee effective counting rate higher than 100K-CPS.
High power X-ray tube (tungsten target – beryllium window) and sophisticated collimation filter system
Advantage: higher excitation efficiency for precious metals, good for precious metal index detection.

Easy operation
Fine positioning system
Industrial ultra-high definition camera and 2D movable platform ensure accurate sample positioning Tiny sample detection – minimum 0.2mm
8 collimators and 4 filters provide free selection according to different sample
The smallest 0.2 mm collimator allows detecting tiny sample

FP Software
FP Software is easy to use and comes with all the advanced features necessary for Precious Metals testing
Fast Analysis thanks to automatic curve function and one-key operation, no bother to choose the curve
Single and multiple points testing (several points test and export the testing results and average value respectively)
Three sets of software can be equipped: precious metal content analysis software, precious metal harmful elements testing and precious metal plating thickness software (for your recommendation)
