EDX8000 is the new generation model after EDX3000 and EDX3000 plus.
Integrated high power x-ray tube with Cu-target and high resolution of SDD detector appr 135eV to increase lifetime of instrument, more stability and more accurate
the new software integrated the newest technology of noise process and CorrectionTM function to increase repeatability and accuracy so that result closest possibly to ICP-OES and Fireassay method. In addition, the CorrectionTM function allows engineers and users to calibrate and operate easier and more flexible than previous models, this function designed to meet new request for testing certified sample traced to NIST standard- USA
Model EDX8000 can test all of precious metals at solid or powder or liquid with accurate result, fast and especially very low repeatability In addition, the EDX8000 also can test thickness of precious and other metals on any basement from single layer to multi-layer

Features:
1.Used to test all kind of sample from 0-99.999% included heavy metals in fake gold like Os, Ir, Ru, W,…
2.Able to distinguish narrow range of sample like 99, 99.1, 99.2, 99.3, 99.4, 99.5, 99.6, 99.7, 99.8, 99.9 And 99.99
3.Able to test thickness of metals at any basements from single layer to multi-layer: Option
4.Able to test precious metals in liquid: Option

Specifications:
Main elements calibrated (can add more): Au, Ag, Cu, Ni, Zn, Pd , Rh, Ru, Cd, Sn, In, Ge, Pt, Os, Ir, W, Re, Ti, Cr, Zr, Co, Pb, Fe, Mn, , Mo …
Built-in CorrectionTM function
FP thick software: Optional
Content range: 1ppm-99.99% (0% to 99.99%)
Solve scatter problem in gold sample
Test time: 30-200s (adjustable)
Used newest DSP and noise process technology helps identify fast heavy metal in fake gold
Number of channels: 4096 Channels
High voltage supply, Detector, Digital MCA and X-ray tube made from USA and UK allow fast test, more stable and increase lifetime than another instruments in the market.

Configurations:
High voltage supply made by Spellman – USA
High resolution detector appr.135eV made by Amptek-USA
Digital MCA 4096 channels made by Amptek-USA
High power x-ray tube Cu-target type with inner core of Oxford UK sealed by
Data transportation by Ethernet protocol
Operating temperature:15-300C
Relative humidity:35%-70%
No need prepare sample contains Lead before test
Application for Bank, Certified testing center, Jewelry factories or Shops,..
Test precious metals in liquid: Option

Please contact our Exclusive Dealer locally for more details
