Instrument introduction

EDX3000 incorporates Skyray’s years of experience in precious metal testing with its unique product configurations and fully functional software. Its ergonomically design and friendly software interfaces grant the users a simple measurement job.

Performance characteristics

Stable X-ray tube
Electric-cooling Si-Pin detector instead of liquid nitrogen cooling detector
Skyray patent product-Signal-to-Noise Enhancer (SNE) improves the stability and accuracy of the measurement greatly.
In-built high resolution camera, convenient for users to analyze samples at any moment
Digital pulse processor handles the data rapidly and accurately
Amplifier circuit
High and low voltage power
Single sample chamber, open and close manually, safe and convenient
Non-vacuum Chamber
Triple safety protection mode
Multi-variant non-linear regression procedure
independent matrix effect correction model
Overall steel structure; elegant and fashionable
Specially developed software with friendly interface
Accurate measurement even when no standard sample
Timely display of high definition graphs, carefree measurement

Technical specifications

Model: EDX3000
Measurable elements: Au, Ag, Pt, Pd, Cu, Zn, Ni, etc.
Analysis accuracy: 0.05%（above 96%）
Analysis range: 1ppm-99.99%
Forms of samples: powder, solid and liquid
Working voltage: AC 110V/220V (AC purified stabilized voltage power supply is suggested)
Ability of simultaneous analysis: 24 elements
Energy Resolution: (155±5）eV
Measurement time: 60-200s
Tube voltage: 5-50kV
Tube current: 50 -1000μA
Ambient temperature: 15℃-30℃
Ambient humidity: 35%-70%
Weight: 30KG

Standard configurations

Si-Pin detector
High voltage 5kv-50kv
X-ray tube 50uA-1000uA
SNE
MCA
Single sample chamber

Application fields

Au, Ag, Pt, Pd, Cu, Zn, Ni, etc.
Electronic and Electric Appliances (RoHS)
Toy & Ceramics
Metallurgy & Minerals
