ECscan10L Pocket Conductivity Tester

short description:

Economical pocket conductivity tester for measurement of low conductivity liquids, accuracy: 1% F.S.


Product Detail

Product Tags

Features

• Low-range pocket conductivity tester is equipped with a platinum sensor.

• 1 point push-button calibration allows using the custom calibration solution.

• Automatic temperature compensation corrects the conductivity measurment to reference temperature.

• Hold function momentarily freezes reading for easy viewing and recording.

• Auto-Power Off effectively conserves battery life.

• Replaceable electrode module reduces maintenance and replacement cost.

• Waterproof feature to ensure complete protection in harsh environment.

1

Applications

• Drinking water

• Education and other industrial applications

Specifications

   Model ECscan10L
   Conductivity
   Range 1.0 to 199.9µS/cm
   Resolution 0.1µS/cm
   Accuracy ±1% F.S.
   Calibration Point 1 point
   Calibration Solution 146.5µS/cm
   Temperature
   Range 0 to 50°C
   Resolution 1°C
   Accuracy ±1°C
   General Specifications
   Temperature Compensation 0 to 50°C, automatic
   Temperature Coefficient 2%/°C, linear
   Reference Temperature 25°C
   Cell Constant K=1
   Hold Function Manual
   Auto-Power Off 8 minutes after last key pressed
   Sensor Type ECSCAN-C1-100K
   Display Single-line LCD (21×21mm)
   Power 3×1.5V LR44 micro alkaline batteries
   Battery Life Approximately 150 hours of continuous use
   Dimensions 185(L)×40(Dia.)mm
   Weight 100g
